Decorative Concrete Topping

VersaTop™


Applicator Installed

• Achieve a variety of looks at an affordable price.
• Compatible with a wide range of approved sands, including locally sourced pit sands
• Formulated to hold aggregate at the floor surface to reduce grinding requirements.
• In many cases can be ground next day or weeks later with no change in difficulty.
• Compressive strengths above 5,000 psi make it ideal for commercial, retail, and institutional projects.


Contact Your Local Rep

Application:
Commercial and multifamily new construction and renovations

Subfloor:
Interior floors including: wood and concrete; terrazzo, ceramic, quarry, and
marble tile; old vinyl tile; radiant heat floors and as part of Maxxon Acousti-Mat
sound control systems

Technical Data

Installation Depths3/8"–3" (9.5–76 mm) For deeper pours, contact Maxxon
Compressive StrengthTypically 5,000 psi (34.5 MPa)
Dry Density115–125 lbs/ft3 (1,842–2,002 kg/m3)
Packaging80 lb bag
Storage Temperature50–100 °F (10–38 °C).
Dry Time3/8" (9.5 mm) thickness drying time is usually next day,
1/2" (12.7 mm) thickness drying time is usually 48 hours,
3/4" (19 mm) thickness drying time is typically 5 to 7 days,
1" (25 mm) dry time is usually 7–10 days.
Installation TemperatureAbove 50 °F (10 °C) for at least 24 hours prior to installation and until underlayment has set.

UL Fire Resistance-Rated Designs

UL Design
G230 J924 L212 L515 L533 L551 L574 M504
G516 J927 L501 L516 L534 L552 L576 M505
G524 J931 L502 L517 L535 L556 L577 M506
G551 J957 L503 L518 L536 L557 L579 M507
G553 J958 L504 L519 L537 L558 L581 M508
G560 J991 L505 L520 L538 L560 L583 M510
G561 J994 L506 L522 L539 L562 L585 M511
G563 L006 L507 L523 L540 L563 L588 M513
G566 L201 L508 L524 L541 L564 L589 M514
G574 L202 L509 L525 L542 L565 L590 M515
G587 L206 L510 L526 L543 L567 L592 M517
G597 L208 L511 L527 L545 L569 L593 M518
J917 L209 L512 L528 L546 L570 M500 M519
J919 L210 L513 L529 L547 L571 M502 M530
J920 L211 L514 L530 L549 L573 M503 M531

ULC Design
I530 L201 L512 M501 M514 M521
L003 L511 M500 M503 M520

For more information on current UL and ULC Designs, contact Maxxon Corporation.

Sample USGBC LEED Credit Areas*
Project Credit Category
Environmental Quality EQ 2 Low Emitting Materials
EQ 4 Indoor Air Quality Assessment
EQ 9 Acoustic Performance
Materials & Resourcs MR 3 Building Product Disclosure and Optimization - Sourcing Raw Materials

* Credits may vary depending on project type and Maxxon products used.

VersaTop™ is GREENGUARD and GREENGUARD Gold Certified.

For additional information on GREENGUARD from UL Envronment, the USGBC, and VersaTop™'s qualifications for earning LEED points, please see our "Go Green" page.

Code Listings:
