Floor underlayment

Level-Right®


Applicator Installed

  • Self-leveling hydraulic cement-based underlayment designed for capping concrete, existing floor goods and adhesive residue
  • High compressive strengths
  • No special subfloor prep, old floor removal or hand finishing required
  • Suitable for both large projects and small repair jobs

Application
Commercial renovation as well as pre-cast, poured-in-place and prestressed concrete construction.

Subfloor
Interior wood, concrete, terrazzo, ceramic, quarry, marble tile, old vinyl tile and radiant heat floors.
Technical Data
Installation DepthsFrom featheredge to 3” (0 – 76 mm). For deeper pours, contact Maxxon Corporation.
Compressive StrengthTypical range of 5,000 – 7,000 psi (34.5 – 48.3 MPa)
Dry Density115-125 lbs./ft3 (1842-2002 kg/m3)
Packaging80lbs bag
Storage Temperature50 - 100 °F (10 - 38 °C)
Dry Time3/4" (19 mm) thickness drying time is usually 5 to 7 days, while 1" (25 mm) dry time is usually 7-10 days
Installation TemperatureAbove 50 °F (10 °C) for at least 24 hours prior
Concrete Surface TemperatureAbove 50 °F (10 °C) for at least 24 hours prior
Trade TrafficTrade traffic may resume 24 hours after installation
Fire Performance (ASTM E84)Flame Spread – 0
Fuel Contribution – 0
Smoke Development – 0
UL Fire Resistance-Rated Designs
UL Design
G230 J924 L212 L515 L533 L551 L574 M504
G516 J927 L501 L516 L534 L552 L576 M505
G524 J931 L502 L517 L535 L556 L577 M506
G551 J957 L503 L518 L536 L557 L579 M507
G553 J958 L504 L519 L537 L558 L581 M508
G560 J991 L505 L520 L538 L560 L583 M510
G561 J994 L506 L522 L539 L562 L585 M511
G563 L006 L507 L523 L540 L563 L588 M513
G566 L201 L508 L524 L541 L564 L589 M514
G574 L202 L509 L525 L542 L565 L590 M515
G587 L206 L510 L526 L543 L567 L592 M517
G597 L208 L511 L527 L545 L569 L593 M518
J917 L209 L512 L528 L546 L570 M500 M519
J919 L210 L513 L529 L547 L571 M502 M530
J920 L211 L514 L530 L549 L573 M503 M531
ULC Design
I530 L201 L512 M501 M514 M521
L003 L511 M500 M503 M520

For more information on current UL and ULC Designs, contact Maxxon Corporation.

Sample USGBC LEED Credit Areas*
Project Credit Category
Environmental Quality EQ 2 Low Emitting Materials
EQ 4 Indoor Air Quality Assessment
EQ 9 Acoustic Performance
Materials & Resourcs MR 3 Building Product Disclosure and Optimization - Sourcing Raw Materials

* Credits may vary depending on project type and Maxxon products used.

Level-Right® is GREENGUARD and GREENGUARD Gold Certified.

For additional information on GREENGUARD from UL Envronment, the USGBC, and Level-Right®'s qualifications for earning LEED points, please see our "Go Green" page.

Code Listings:
